SICK 1064705
SICKNot available

GL10G-N1251

Photoelectric sensors: G10
Product Code: 1064705
Partner cod.: 1064705
SICK


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Tecnichal data
Features
Functional principlePhotoelectric retro-reflective sensor
Functional principle detailDual lens
Dimensions (W x H x D)20 mm x 50 mm x 39 mm
Housing design (light emission)Rectangular
Sensing range max.

0.15 m ... 12 m

0.15 m ... 10 m

Sensing range

0.3 m ... 9.5 m

0.3 m ... 8 m

Type of lightVisible red light
Light sourcePinPoint LED
Light spot size (distance)Ø 58 mm (5 m)
Wave length625 nm
AdjustmentPotentiometer, 270°
Special applicationsDetecting transparent objects
Mechanics/electronics
Supply voltage10 V DC ... 30 V DC
Ripple< 5 Vpp
Current consumption20 mA
Switching outputNPN
Switching modeLight/dark switching
Switching mode selectorSelectable via light/dark selector
Output current Imax.≤ 100 mA
Response time≤ 1 ms
Switching frequency500 Hz
Connection typeCable, 3-wire, 2 m
Cable materialPVC
Conductor cross section0.14 mm²
Circuit protection

Protection classIII
Weight90 g
Polarisation filter
Housing materialPlastic, ABS/PMMA
Enclosure ratingIP67
Electromagnetic compatibility (EMC)EN 60947-5-2
Ambient operating temperature–30 °C ... +60 °C
Ambient temperature, storage–40 °C ... +70 °C
UL File No.NRKH.E348498 & NRKH7.E348498
More standardsUL325 10)
Classifications
eCl@ss 5.027270902
eCl@ss 5.1.427270902
eCl@ss 6.027270902
eCl@ss 6.227270902
eCl@ss 7.027270902
eCl@ss 8.027270902
eCl@ss 8.127270902
eCl@ss 9.027270902
eCl@ss 10.027270902
eCl@ss 11.027270902
eCl@ss 12.027270902
ETIM 5.0EC002717
ETIM 6.0EC002717
ETIM 7.0EC002717
ETIM 8.0EC002717
UNSPSC 16.090139121528
Technical Specs
Unit weight0.123 Kilograms
Net unit weight0.123 Kilograms
Unit volume803.25 Cubic Centimetres (cm³)
Measurements8.500*7.000*13.500
Country of originMalaysia
EAN4047084404436
