| Suitable for illumination | Yes |
| Lamp type | LED lamp |
| Rated supply voltage | 12...130V AC/DC |
| Power module type | Full voltage or universal |
| Lamp test type | Standard |
| Contact operation for Logic Reed contact blocks | Snap action |
| Contact operation for sealed switch contact blocks | Snap action |
| Contact operation for mini contact blocks | Slow, double make and break |
| Contact operation for low voltage contact blocks | Slow, double make and break |
| Dielectric strength | 2200V for 1 minute, 1300V for 1 minute (Logic Reed) |
| Electrical life cycle | 1000000 cycles at maximum rated load, 200000 cycles at maximum rated load (Logic Reed) |
| Spring-return | Yes |
| Type of electric connection | Screw connection |
| Mechanical life operations | 250000 minimum |
| Operator type | Momentary, illuminated |
| Typical operating force for 2-position push-pull | 9 lb maximum push or pull |
| Shock | 1/2 cycle sine wave for 11 ms ââ°¥25 G (contact fragility) and no damage at 100 G |
| Degree of protection | Type 7 & 9 explosion proof (Type 3 and Type 4 ratings available with accessories) |
| Vibration | 10...2000 Hz, 1.52 mm displacement (peak-to-peak) maximum/10 G maximum (except Logic Reed) |
| Typical operating force for standard contact blocks (800T-XA) | 1 lb |
| Terminal screw torque | 6 lb.in |
| Wire gauge | 18 AWG |
| Typical operating force for Logic Reed contact blocks | 1 lb maximum |
| Typical operating force for jumbo mushroom operator without contact blocks | 2.9 lb maximum |
| Typical operating force for flush, extended, standard mushroom operator without contact blocks | 2.9 lb maximum |
| Typical operating force for sealed switch contact blocks | 3 lb maximum at 0.205 inch plunger travel |
| Typical operating force for 3-position push-pull | 12 lb maximum push to in position or pull to center position (15 lb maximum pull to out position) |
| Material front ring | Plastic |
| Colour button | Other |
| Finger-safe guards | No guards on terminals |
| Lens color | Multi-color insert packet |
| Contact block | No contact blocks |
| With front ring | Yes |
| Construction type lens | Round |
| Operating temperature | -20 ðC |
| Humidity | 50% at 104 ðF (40 ðC) |
| Storage temperature | -40 ðC |
| Typical operating force for stackable sealed switch contact blocks | 1 lb maximum |
