Available

800F 3 Position Selector Switch - Metal, Spring Return from Left, Black, Standard Knob, Standard Orientation, Standard Pack (Qty. 1)

800F 3 Position Selector Switch - Metal, Spring Return from Left, Black, Standard Knob, Standard Orientation Standard Pack (Qty. 1)

Product Code: 800FM-SL32 Copia - Copy

Partner cod.: 800FM-SL32 Copia - Copy

ROCKWELL AUTOMATION

Tecnichal data

Technical Specs

Tecnichal data

Number of switch positions	3
Switching function latching	No
Material front ring	Metal
Colour control element	Black
Operator cap color	Black
Operator construction/material	Metal
Operator cap/button material	Metal
Latch material	Metal
With front ring	Yes
Type of control element	Short thumb-grip
Suitable for illumination	No
Spring-return	Yes
Switch orientation	Standard
Packaging	Standard pack (1 per package)
Operator type	Selector switch - standard knob
Operator function	Spring return from left, 3 position
Enclosure compatibility	IP66, Type 4/13 (round metal operator)
Hole diameter	22.5 mm
Vibration	10 G
Shock	100 G
Operator mechanical design life (cycles, min.)	1000000
Hazardous location rating	No
Operating temperature	-25 Ã°C
Storage temperature	-40 Ã°C
Humidity	Ã¢Ã¢°¤95% RH from 25...60 Ã°C (77...140 Ã°F)
Certifications	UL,UR, CSA, CCC, CE

Technical Specs

Specifications
Called From 800FC Library:No
Selector Switch Data
Operator Construction:Round Metal (Type 4/13, IP66)
Operator Type:Selector Switch - Standard Knob
Operator Function:Spring Return from Left, 3 Position
Knob Color:Black
Orientation:Standard
Packaging:Standard Pack, Quantity:1
Back Of Panel Data
Mounting Style:No Contact Blocks
Part Numbers:No Back of Panel Part Numbers
Target Table Selections:Cam and Contact Blocks
