| Degree of protection (IP) | IP20 |
| Shock | 15 G peak for 11 ms duration (ñ1.0 ms) |
| Vibration | 0.152 mm (0.006 inch) displacement, 1 G peak |
| Number of analogue outputs | 2 |
| Mains voltage | 400 V |
| Integrated breaking resistance | No |
| Number of digital inputs | 6 |
| Number of digital outputs | 3 |
| Number of analogue inputs | 2 |
| Supporting protocol for DeviceNet | Yes |
| Max. output frequency | 420 Hz |
| Supporting protocol for EtherNet/IP | Yes |
| Line voltage, nom | 400V @ 380...480V drive rating, 400V nominal motor voltage |
| Mains frequency | 50 Hz |
| Efficiency | 97.5% at rated amps, nominal line volts |
| Number of phases output | 3 |
| Number of phases input | 3 |
| Relative symmetric net voltage tolerance | 10 % |
| With control element | Yes |
| Supporting protocol for LON | Yes |
| Supporting protocol for TCP/IP | Yes |
| Supporting protocol for PROFIBUS | Yes |
| Supporting protocol for CAN | Yes |
| Supporting protocol for Modbus | Yes |
| Input frequency tolerance | 47 Hz |
| Altitude | 1000 m (3300 ft.) maximum without derating |
| Degree of protection (NEMA) | 1 |
| Operating temperature | 40 ðC @ 400V AC |
| Storage temperature | -40 ðC |
| Relative humidity | 5...95% noncondensing |
