ROCKWELL AUTOMATION 1585D-M8UGDM-35
ROCKWELL AUTOMATIONNot available

Ethernet Media, M12 X-CODE, Straight Male, 8 conductors (4-pair), Foil and Braided Shield PUR, X-CODE, Straight Male, Cat 6, Gigabit, 35 m

Ethernet Media, M12 X-CODE, Straight Male, 8 conductors (4-pair), Foil and Braided Shield PUR, X-CODE, Straight Male, Cat 6, Gigabit, 35 m
Product Code: 1585D-M8UGDM-35
Partner cod.: 1585D-M8UGDM-35
ROCKWELL AUTOMATION


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Tecnichal data
Cable length35 m
Enclosure type ratingIP67
Connector typeFirst: M12, Second: M12
Connector orientationFirst: straight male, Second: straight male
Cable ratingShielded: Standard TIA 568-B, ISO/IEC 11801, Flexrated, 26 AWG, Halogen-free, Type CMX
Cable typeShielded: teal PUR, 4 Twisted pairs, 26 AWG, Industrial Cat 6, Sunlight- and oil-resistant
Type of outer conductorFoil + braiding
Halogen free according to EN 60754-1/2Yes
Number of conductors8 Conductors
Operating temperature-40 to 80 °C
Armouring/reinforcementBraiding
Nominal outer diameter5.84 mm ±10%
Bend radius10 x cable diameter
MaterialCoupling nut: Nickel-plated brass, housing: polyurethane (PUR), contact: Gold-plated brass
