Ethernet Media, Cable Spool, Standard, Cable Spool, 4 conductors (2-pair), Teal 26AWG Flex LSZH PUR, Foil and Braided Shield, 100BASE-TX, 1 00 Mbit/s, No connector , flying leads, No Connector, Shielded, 300 Meters, Standard

1585 EtherNet Cable Spools, 4 Conductors, Teal PUR, Shielded, High Flex, PUR, Halogen Free, 10 million cycles

Product Code: 1585-C4UB-S300

Partner cod.: 1585-C4UB-S300

ROCKWELL AUTOMATION

Tecnichal data

Technical Specs

Tecnichal data

Number of stranding elements	4
Cable type	SF/FTP
Screen over stranding	Foil + braiding
Cable length	300 m
Bend radius	10 million cycles at 20 x diameter (PUR cable)
Material	Conductor: tinned copper stranded, insulation: high-density polyethylene
Conductor material	Copper
Stranding	Bundle
Special characteristic	Shielded
Category	5E
AWG size	26
Stranding element	Pairs
Material outer sheath	Polyurethane (PUR)
Cable rating	C(ETL)US TYPE CMX, TIA 568-B, Flex rated, Halogen-Free
Cable geometry	Round
Conductor surface	Tinned
Voltage	300 V
Suitable as telephone cable	Yes
Diameter	6.2 Ã± 12 mm
Data rate	Up to 1 GB/s, Cat 5e
Number of conductors	4 conductors (2-pair)
UV resistant	Yes
Suitable for underground installation	Yes
Suitable as computer data cable	Yes
Suitable as signalling cable	Yes
Core identification	Colour
First end description	Cable spool
Cable bandwidth	100BASE-TX, 100 Mbit/s, IEEE 802.3 fast ethernet over copper wiring
Operating temperature	-40 Ã°C

Technical Specs

Specifications
Shield:Teal Halogen Free PUR - Foil and Braided Shielding
Number Of Pins:4 Conductors
Length:300 Meters
Cable Data
Cable Type:Teal Halogen Free PUR - Foil and Braided Shielding
Number of Conductors:4 Conductors
Cable Rating:High Flex, PUR, Halogen Free, 10 million cycles
Standard or Build-to-Order Cable Length:300 Meters
