Not available

Contactor, 23 A, 24V 50/60 Hz, AC, 4 Normally Open Poles, 24V AC 50/60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

100-C IEC Contactor, 24V 50/60Hz, Screw Terminals, Line Side, 23A, 4 N.O. 0 N.C. Main Contact Configuration, Single Pack

Product Code: 100-C23KJ400 Copia - Copy

Partner cod.: 100-C23KJ400 Copia - Copy

ROCKWELL AUTOMATION

Tecnichal data

Technical Specs

Download

Tecnichal data

Product TypeSpare PartCatalog NumberTC-855DescriptionCoil,24V 50/60HZ For ContactorQuantity1

Technical Specs

Specifications
Connection:Screw Terminals
3-Phase kW (50 Hz) 230V Rating:7.5
3-Phase kW (50 Hz) 400V/415V Rating:11
3-Phase kW (50 Hz) 500V Rating:13
3-Phase kW (50 Hz) 690V Rating:10
3-Phase HP (60 Hz) 230V Rating:7.5
3-Phase HP (60 Hz) 460V Rating:15
3-Phase HP (60 Hz) 575V Rating:15
Contactor Data
Terminal Type:Screw Terminals
Rated Operating Current, AC-3:23A
Coil Voltage:24V 50/60Hz
No. of Poles:4 Poles
Coil Termination:Line Side
Contact Configuration:4 N.O. 0 N.C. Main Contact Configuration
Package Quantity:1
Application Data
Electrical Standards:UL
Load Data [Optional]
Utilization Category:AC-3 Squirrel-cage motor starting and stopping
Life Data [Optional]
Actual Life:Actual Life Cannot be Calculated (more information)...
Terminal Marking Positions Used
100-C or 104-C Contactor:None
Front Mounted Auxiliary Contact:None
Left Side Auxiliary Contact:None
Right Side Auxiliary Contact:None
Interlock:None

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

100-td013_-en-p.pdf
