| Product properties | Product type: Corrugated pipe screw connection Application: Cable gland Type of the screw connection: Conduit adapter Type: Outer thread Cable outlet: straight Thread type: Pg |
| Dimensions | Width: 29.5 mm Height: 46 mm Wrench size for mounting: 27 mm External dimensions Outside diameter: 16.5 mm |
| Material specifications | Material: PA 6 Flammability rating according to UL 94: V0 Material for screw connection: PA Components: free from silicone, halogen, and cadmium |
| Cable/line | Halogen-free: yes |
| Mechanical properties | Mechanical data Type of the screw connection: Conduit adapter |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Ambient temperature (operation): -40°C ... 120°C |
| Mounting | Wrench size: 27 mm |
