PHOENIX CONTACT 3240794
PHOENIX CONTACTAvailable

WT-ID HF 2,5X98 BU - Cable tie

Cable binders for quick and secure fastening, can be detected using metallic pigments
Product Code: 3240794
Partner cod.: 3240794
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Description
Download
Tecnichal data
Product propertiesProduct type: Cable tie
Type: Internal teeth
Tensile strength GRP: 80 N
DimensionsWidth: 2.5 mm
Length: 98 mm
Material specificationsColor: blue
Material: PA 6.6
Flammability rating according to UL 94: V2
Components: free from silicone and halogen
Cable/lineExternal cable diameter: 1 mm ... 21 mm
Tensile strength: 80 N
Environmental and real-life conditionsAmbient conditions
Optimum ambient temperature (storage/transport): 23°C 50 % Polyamide 6.6 has pronounced hygroscopic properties. It absorbs or releases water in accordance with the level of humidity within its environment. Its properties are ideal when the percentage of water is 2 - 3%. The packaging, which is tailored specifically to the product concerned, contains the optimum level of moisture.To ensure that the ideal properties are maintained, the following points should be observed during storage: Keep product stored inside sealed original packaging, carry out any product processing soon after breaking open the packaging, avoid direct sunlight, avoid direct heat.
Ambient temperature (operation): -40°C ... 85°C
Ambient temperature (assembly): -10°C ... 60°C
Resistance to UV radiation: no
Short-term temperature: 110°C
Standards and regulationsResistance to UV radiation: no
MountingMounting type: Cannot be removed
Technical Specs
ECLASSECLASS-11.0: 27140702
ECLASS-12.0: 27140702
ECLASS-13.0: 27140702
ETIMETIM 9.0: EC000046
UNSPSCUNSPSC 21.0: 39121700
Description
Cable binders for quick and secure fastening, can be detected using metallic pigments
