2963747 PHOENIX CONTACT - Technology Bsa

PSR-SCP- 24UC/URM/5X1/2X2 - Coupling relay

Safe coupling relay with force-guided contacts, 5 N/O contacts, 2 N/C contacts, 1-channel, plug-in screw terminal block, width: 22.5 mm

Product Code: 2963747 Copia - Copy

Partner cod.: 2963747 Copia - Copy

PHOENIX CONTACT

Product properties	Product type: Coupling relay Product family: PSRclassic Application: Safe switch off High demand Low demand Mechanical service life: 10x 10⁶ cycles Relay type: Electromechanical relay with force-guided contacts in accordance with IEC/ENÃ61810-3 Times Restart time: < 1 s (Boot time)
Electrical properties	Maximum power dissipation for nominal condition: 8.56 W (at U_BÃ=Ã26.4ÃVÃDC, U_SÃ=Ã24ÃV, I_SÃ=Ã47ÃmA, nÃ=Ã1, I_L²Ã=Ã72ÃA², R_contactÃ=Ã0.1ÃÃ¯Ã¢¦Ã¢) Nominal operating mode: 100% operating factor Air clearances and creepage distances between the power circuits Rated insulation voltage: 250 V Rated surge voltage/insulation: Safe isolation 4ÃkV between all current paths and housing
Input data	General Rated control circuit supply voltage U_S: 24 V AC/DC -15Ã% / +10Ã% Power consumption at U_S: typ. 1.2 W Rated control supply current I_S: typ. 47 mA Input voltage range: 20.4 V AC/DC ... 26.4 V AC/DC Inrush current: typ. 350 mA DC (ÃÃ¢tÃ<Ã1ÃÃµs at U_s) typ. 350 mA AC (ÃÃ¢tÃ=Ã2Ãms at U_s) Typ. starting time with U_s: typ. 20 ms (when controlled via A1) Typical release time: typ. 20 ms (when controlled via A1) Recovery time: < 500 ms Maximum switching frequency: 0.5 Hz Protective circuit: Surge protection; Varistor Operating voltage display: 1 x green LED
Output data	Contact switching type: 5 enabling current paths 2 confirmation current paths Contact material: AgSnO₂ Maximum switching voltage: 230 V AC/DC (Observe the load curve) Minimum switching voltage: 5 V AC/DC Limiting continuous current: 6 A (N/O contact) 3 A (N/C contact) Maximum inrush current: 6 A Inrush current, minimum: 10 mA Sq. Total current: 72 A² Interrupting rating (ohmic load) max.: 144 W (N/O contact, 24 V DC, ÃÃ¢ = 0 ms) 288 W (N/O contact, 48 V DC, ÃÃ¢ = 0 ms) 240 W (N/O contact, 60 V DC, ÃÃ¢ = 0 ms) 110 W (N/O contact, 110 V DC, ÃÃ¢ = 0 ms) 88 W (N/O contact, 220 V DC, ÃÃ¢ = 0 ms) 1380 VA (N/O contact, 230 V AC, ÃÃ¢ = 0 ms) Maximum interrupting rating (inductive load): 42 W (N/O contact, 24 V DC, ÃÃ¢ = 40 ms) 42 W (N/O contact, 48 V DC, ÃÃ¢ = 40 ms) 42 W (N/O contact, 60 V DC, ÃÃ¢ = 40 ms) 42 W (N/O contact, 110 V DC, ÃÃ¢ = 40 ms) 42 W (N/O contact, 220 V DC, ÃÃ¢ = 40 ms) Switching capacity: min. 50 mW Switching capacity in accordance with IEC 60947-5-1: 3 A (24ÃV (DC13)) 3 A (230ÃV (AC15)) Switching capacity (360/h cycles): 4 A (24ÃV (DC13)) 4 A (230ÃV (AC15)) Output fuse: 10 A gL/gG (N/O contact) 4 A gL/gG (N/O contact, for low-demand applications) 6 A gL/gG (N/C contact)
Connection data	Connection technology pluggable: yes Conductor connection Connection method: Screw connection Conductor cross section rigid: 0.2 mm² ... 2.5 mm² Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross-section AWG: 24 ... 12 Stripping length: 7 mm Screw thread: M3 Tightening torque: 0.6 Nm
Dimensions	Width: 22.5 mm Height: 114.5 mm Depth: 99 mm
Material specifications	Housing material: Polyamide
Characteristics	Safety data Stop category: 0 Safety data: ENÃISOÃ13849 Category: 1 Performance level (PL): c Safety data: IEC 61508 - High demand Safety Integrity Level (SIL): 1 Safety data: IEC 61508 - Low demand Safety Integrity Level (SIL): 1 Safety dataÃ¢Ã¢¬Ã¢¹ Safety Integrity Level (SIL): 1
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Min. degree of protection of inst. location: IP54 Ambient temperature (operation): -20°C ... 55°C Ambient temperature (storage/transport): -40°C ... 85°C Maximum altitude: max. 2000 m (Above sea level) Max. permissible humidity (storage/transport): 75 % (on average, 85% infrequently, non-condensing) Max. permissible relative humidity (operation): 75 % (on average, 85% infrequently, non-condensing) Shock: 15g (In the event of stress caused by shock, contact reactions are possible for up to 2Ãms.) Vibration (operation): 10ÃHzÃ...Ã150ÃHz, 2g (In the event of stress caused by vibration, contact reactions are possible for up to 1Ãms.)
Approvals	CE Certificate: CE-compliant
Standards and regulations	Air clearances and creepage distances between the power circuits Standards/regulations: DINÃENÃ50178
Mounting	Mounting type: DIN rail mounting Mounting position: any Connection method: Screw connection
