MKDSP 25/ 5-15,00 S - PCB terminal block

PCB terminal block, nominal current: 125 A, rated voltage (III/2): 1000 V, nominal cross section: 35 mm², number of potentials: 5, number of rows: 1, number of positions per row: 5, product range: MKDSP 25, pitch: 15 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0°, color: green, Pin layout: Linear pinning, Solder pin [P]: 4.5 mm, number of solder pins per potential: 4, type of packaging: packed in cardboard. Avoid placing permanent mechanical loads on the terminal

Product Code: 1864930

Partner cod.: 1864930

PHOENIX CONTACT

Product properties	Product line: COMBICON Terminals XL Product type: Printed circuit board terminal Product family: MKDSP 25 Number of positions: 5 Pitch: 15 mm Number of connections: 5 Number of rows: 1 Number of potentials: 5 Pin layout: Linear pinning Solder pins per potential: 4
Electrical properties	Nominal current I_N: 125 A Nominal voltage U_N: 1000 V Degree of pollution: 3 Rated voltage (III/3): 1000 V Rated surge voltage (III/3): 8 kV Rated voltage (III/2): 1000 V Rated surge voltage (III/2): 8 kV Rated voltage (II/2): 1000 V Rated surge voltage (II/2): 8 kV
Connection data	Connection technology Type: Standard Nominal cross section: 35 mm² Conductor connection Connection method: Screw connection with tension sleeve Conductor cross section rigid: 0.5 mm² ... 35 mm² Conductor cross section flexible: 0.5 mm² ... 35 mm² Conductor cross section AWG: 20 ... 2 Conductor cross section flexible, with ferrule without plastic sleeve: 1 mm² ... 35 mm² Conductor cross section, flexible, with ferrule, with plastic sleeve: 1.5 mm² ... 35 mm² 2 conductors with same cross section, solid: 0.5 mm² ... 6 mm² 2 conductors with same cross section, flexible: 0.5 mm² ... 6 mm² 2 conductors with same cross section, flexible, with ferrule without plastic sleeve: 0.5 mm² ... 4 mm² 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve: 0.5 mm² ... 16 mm² Stripping length: 18 mm Tightening torque: 2.5 Nm ... 4.5 Nm (<Ã25Ãmm²Ã=Ã2.5ÃNm, Ã¢Ã¢°¥Ã25Ãmm²Ã=Ã4.5ÃNm) Information on the aluminum conductor Cross section / torque / form of conductor: Cable cross section:35 mm²; Torque:4.5 Nm; Form of cable:round, single-strand, class 1(re) Specification: DINÃVDEÃ0276-603 (VDEÃ0276-603):2010-03 Note on conductor pretreatment: The following measures are required for durable and reliable contacting of the aluminum conductor: the stripped end of the aluminum conductor must be separated from the oxide layer using a blade, and immediately dipped in non-acid and non-alkali Vaseline. The pretreatment must be repeated when connecting the conductors anew.
Mounting	Mounting type: Wave soldering Pin layout: Linear pinning Drive form screw head: SlottedÃ(L) Connection method: Screw connection with tension sleeve Processing notes Process: Wave soldering
Material specifications	Material data - contact Note: WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 Contact material: Cu alloy Surface characteristics: Tin-plated Metal surface terminal point (top layer): Tin (5 - 7 Ãµm Sn) Metal surface soldering area (top layer): Tin (5 - 7 Ãµm Sn) Material data - housing Color (Housing): green (6021) Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0 Glow wire flammability index GWFI according to ENÃ60695-2-12: 850 Glow wire ignition temperature GWIT according to ENÃ60695-2-13: 775 Temperature for the ball pressure test according to ENÃ60695-10-2: 125°C
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/158b0afe23d1ab408f646eacfe25f655/-S204x204-FJPG Pitch: 15 mm Width [w]: 75 mm Height [h]: 43.5 mm Length [l]: 31 mm Installed height: 39 mm Solder pin length [P]: 4.5 mm Pin dimensions: 1.2 x 1.2 mm PCB design Hole diameter: 1.6 mm
Mechanical tests	Test for conductor damage and slackening Specification: IEC 60999-1:1999-11 Result: Test passed Pull-out test Specification: IEC 60999-1:1999-11 Conductor cross section/conductor type/tractive force setpoint/actual value: 0.5 mm² / solid / > 20 N 0.5 mm² / flexible / > 20 N 35 mm² / stranded / > 190 N 35 mm² / flexible / > 190 N
Electrical tests	Temperature-rise test Specification: IEC 60947-7-4:2013-08 Requirement temperature-rise test: The sum of ambient temperature and temperature rise of the PCB terminal block shall not exceed the upper limiting temperature. Short-time withstand current Specification: IEC 60947-7-4:2013-08 Insulation resistance Specification: IEC 60512-3-1:2002-02 Insulation resistance, neighboring positions: >Ã5ÃMÃ© Air clearances and creepage distances \| Specification: IEC 60664-1:2007-04 Insulating material group: I Comparative tracking index (IEC 60112): CTI 600 Rated insulation voltage (III/3): 1000 V Rated surge voltage (III/3): 8 kV minimum clearance value - non-homogenous field (III/3): 8 mm minimum creepage distance (III/3): 12.5 mm Rated insulation voltage (III/2): 1000 V Rated surge voltage (III/2): 8 kV minimum clearance value - non-homogenous field (III/2): 8 mm minimum creepage distance (III/2): 8 mm Rated insulation voltage (II/2): 1000 V Rated surge voltage (II/2): 8 kV minimum clearance value - non-homogenous field (II/2): 8 mm minimum creepage distance (II/2): 8 mm
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1Ãoctave/min 5g (60.1ÃHzÃ...Ã150ÃHz) Amplitude: 0.35Ãmm (10ÃHzÃ...Ã60.1ÃHz) Test duration per axis: 2.5 h Glow-wire test Specification: IEC 60695-2-10:2000-10 Temperature: 850°C Time of exposure: 5 s Aging Specification: IEC 60947-7-4:2013-08 Ambient conditions Ambient temperature (operation): -40°C ... 100°C (Depending on the current carrying capacity/derating curve) Ambient temperature (storage/transport): -40°C ... 70°C Relative humidity (storage/transport): 30 % ... 70 % Ambient temperature (assembly): -5°C ... 100°C
Packaging specifications	Type of packaging: packed in cardboard
