1658642 PHOENIX CONTACT - Technology Bsa

VS-08-A-RJ45/MOD-1-IP67-BK - Panel mounting frames

RJ45 panel mounting frame, IP67, for modular socket inserts (Keystone), for square panel cutout, with grommet, without mounting screws, color: black

Product Code: 1658642 Copia - Copy

Partner cod.: 1658642 Copia - Copy

PHOENIX CONTACT

Product properties	Type: Version 6 RJ45 Product type: Panel mounting frame Number of positions: 8 Connection profile: RJ45 Application: Modular insert Number of slots: 1 Insulation characteristics Degree of pollution: 2
Electrical properties	Transmission medium: Copper
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/00a1897cbd598540ad4308b2d7ed5f34/-S204x204-FJPG Width: 32.6 mm Height: 32.6 mm Depth: 16 mm Length: 16.3 mm
Material specifications	Color: black Material: Plastic Flammability rating according to UL 94: V0 Seal material: NBR Seal material, flat gasket: NBR Housing surface material: PA, light gray Contact surface material: Au/Ni Contact carrier material: Polyester GF Housing material: Plastic
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 1000
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65/IP67 Ambient temperature (operation): -40°C ... 80°C
Mounting	Mounting type: Front mounting
