PHOENIX CONTACT 1655629
PHOENIX CONTACT 1655629
PHOENIX CONTACTNot available

VS-ST-KX-75-RG179/187 - D-SUB coaxial contact

Coaxial contact, for D-SUB combination inserts, solder cup, pin, straight, for cable RG 179/187, gold-plated
Product Code: 1655629
Partner cod.: 1655629
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Download
Tecnichal data
Product propertiesProduct type: Solder contact
Type: Individual male contact
Contact material type: turned
Series: HC-M-04-KOAX
Electrical propertiesRated voltage (III/3): 250 V
Rated current: 2 A
Insulation resistance: 10 TΩ
Wave impedance: 75 Ω
DimensionsDimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/efc1e493a428e14bbc72b42982884dbd/-S204x204-FJPG
Width: 6 mm
Height: 6 mm
Length: 23 mm
Mechanical characteristics
Contact diameter: 4.8 mm
Material specificationsContact material: Copper alloy
Contact surface material: Hard gold-plated over nickel
Cable/lineExternal cable diameter (): 3.2 mm
Wave impedance: 75 Ω
Mechanical propertiesMechanical data
Insertion/withdrawal cycles: ≥ 500
Insertion force per signal contact: ≤ 7.00 N
Extraction force per signal contact: ≤ 7 N
Environmental and real-life conditionsAmbient conditions
Ambient temperature (operation): -55°C ... 135°C
MountingConnection method: Solder cup
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_05459.pdf

Manufacturer_declaration_13006.pdf

Technical_drawing_18158.pdf
