1499939 PHOENIX CONTACT - Technology Bsa

TCP 32DC/5A F - Thermal device circuit breaker

1-channel thermal device circuit breaker for protecting loads up to 32 V DC in the event of an overload. Fuse type: fast-acting. Can be plugged onto fuse terminal blocks and interfaces for flat plug-in fuse of type C according to standard ISO 8820-3. With fixed nominal current: 5 A

Product Code: 1499939

Partner cod.: 1499939

PHOENIX CONTACT

Product properties	Product type: Thermal device circuit breakers Type: Male Number of positions: 1 No. of channels: 1 Data management status Article revision: 00 Insulation characteristics Protection class: III
Electrical properties	General Rated voltage: max. 32 V DC Rated current I_N: 5 A Required backup fuse: Only required if I_max of the power supply > the short-circuit switching capacity. Rated short-circuit switching capacity I_cn: Ã¢Ã¢°¥3 shutdowns Short-circuit switching capacity: 150 A (Ã¢Ã¢°¥3 shutdowns) 2000 A (Ã¢Ã¢°¥ 1 switch-off) Voltage drop: < 150 mV
Connection data	Connection method: pluggable
Dimensions	Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/168398/full/b1500?format=jpg Width: 6.2 mm Height: 19.7 mm Depth: 29.5 mm
Material specifications	Color: beige (RAL 1001) Material: Copper, tin-plated
Mechanical properties	Mechanical data Open side panel: No
Environmental and real-life conditions	Ambient conditions Degree of protection: IP30 (Actuation area) Ambient temperature (operation): -40 °C ... 85 °C Ambient temperature (storage/transport): -40 °C ... 125 °C
Mounting	Mounting type: on base element
