| Notes | General: for flexible conductors with or without ferrules Connectors may be operated only when there is no load/voltage. For HEAVYCON housing type B6 ... B48 and module carrier frame HC-M-B...MF-... |
| Mounting | Assembly instructions: To ensure correct use, installation in housing with IP54 protection or better is required |
| Product properties | Product type: Modular contact insert Number of positions: 4 Connection profile: 4 Application: Power Number of module slots: 1 No. of power contacts: 4 No. of control contacts: 0 Contact material type: rolled Series: HC-M-04P Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Connection data | Connection technology Connection technology: Push-in connection Connection in acc. with standard: IEC / EN Conductor connection Conductor cross section: 2.5 mm² ... 6 mm² Connection cross section AWG: 14 ... 10 Stripping length of the individual wire: 9.6 mm |
| Dimensions | Mechanical characteristics Minimum housing height: 72 mm Contact diameter: 4 mm |
| Electrical properties | Rated voltage (III/2) contacts: 1000 V Rated voltage (III/3): 830 V Rated surge voltage (III/2): 8 kV Rated surge voltage (III/3): 8 kV Rated surge voltage: 8 kV Rated current: 40 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Ag Contact carrier material: PC Standards/regulations: PC: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 125°C |
| Standards and regulations | Testing Standards/regulations: PC: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3) |
