1415232 PHOENIX CONTACT - Technology Bsa

Product properties	Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 12 No. of conductors: 12
Electrical properties	Attenuation: typ. 0.35 dB max. 0.6 dB Transmission medium: Multi-mode fiberglass
Mechanical properties	Tensile strength short-term/long-term: 500 N / 200 N
Material specifications	Ferrule material: Zirconia ceramics Outer sheath, material: LSFH
Connector	Connection 1 Insertion/withdrawal cycles: 500 (In the event of repeated cleaning) 500 Degree of protection: IP68 (IEC 60529) Ambient temperature (operation): -20°C ... 70°C (IEC 60794-1-2 F1) Number of positions: 12 Locking type: Push Pull Connection 2 Material: Plastic Number of positions: 12 Degree of protection: IP20 (IEC 60529) Locking type: Push Pull
Cable/line	Cable length: 1 m Cable weight: 8.30 kg/km Cable type: Multimode fiberglass Fan out Cable abbreviation: 12-.../(ZN)H-...30 External cable diameter: 7 mm Outer sheath, material: LSFH External sheath, color: orange Wire diameter incl. insulation: 250 Ãµm Individual wire diameter: 250 Ãµm Tensile strength short-term/long-term: 500 N / 200 N Lateral pressure short term: 500.00 N/cm Lateral pressure, long-term: 100.00 N/cm Halogen-free: complying with IEC 60754-1/2
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C (IEC 60794-1-2 F1) Ambient temperature (storage/transport): -20°C ... 70°C (IEC 60794-1-2 F1) Ambient temperature (assembly): -10°C ... 50°C (IEC 60794-1-2 F1)
