| Product properties | Product type: Data cable preassembled Number of positions: 2 |
| Electrical properties | Transmission medium: Multi-mode fiberglass Transmission speed: 10 Gbps |
| Mechanical properties | Tensile strength short-term/long-term: 70 N |
| Material specifications | Flammability rating according to UL 94: V0 Outer sheath, material: LSZH |
| Dimensions | External dimensions External diameter min.: 2 mm External diameter max.: 4 mm |
| Connector | Connection 2 Type: Plug SC duplex |
| Cable/line | Cable length: 1.00 m Cable weight: 5.30 kg/km Cable type: Multimode fiberglass Non-metallicï¼Ã thermoplastic low smoke halogen-free polyolefin Cable abbreviation: I-V(ZN)H Cable structure: Figure 8 cable Outer sheath, material: LSZH External sheath, color: aqua Single wire, number of litz wires: 2 Individual wire diameter: 900 õm Bending radius, long-term: 50 mm Bending radius short term/long term: 30 mm Smallest bending radius, fixed installation: 30 mm Smallest bending radius, movable installation: 7.5 mm Tensile strength short-term/long-term: 70 N Lateral pressure, long-term: 100.00 N/cm Halogen-free: complying with IEC 60754-1/2 Resistance to oil: Not resistant to oil, gasoline, acids, and lyes Concentration of fumes: in accordance with IEC 61034 Flame resistance: yes Behavior in fire: No corrosive or toxic fumes FO cable Number of fibers: 2 Fiber: 50/125Ãõm Fiber type: Multi-mode 50/125Ãõm fiberglass Attenuation: ââ°¤ 3.5 dB/km (with 850 nm) Transmission medium: Multi-mode fiberglass |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 60°C Ambient temperature (storage/transport): -20°C ... 60°C Ambient temperature (assembly): -20°C ... 60°C Ambient temperature (installation): -20°C ... 60°C Resistance to oil: Not resistant to oil, gasoline, acids, and lyes |
| Standards and regulations | Behavior in fire: No corrosive or toxic fumes Flame resistance: yes Resistance to oil: Not resistant to oil, gasoline, acids, and lyes Concentration of fumes: in accordance with IEC 61034 |
