CUC-INI-C1ZNI-S/R4IP10G8 - RJ45 male insert

RJ45 male insert, design: RJ45, degree of protection: IP20, number of positions: 8, 10 Gbps, CAT6_A (IEC 60512-27-100:2008, TIA-568-C.2:2009), material: Metal, connection method: Insulation displacement connection, connection cross section: AWG 23- 22, cable outlet: straight, Ethernet

Product Code: 1157963 Copia - Copy

Partner cod.: 1157963 Copia - Copy

PHOENIX CONTACT

Product properties	Type: RJ45 Product type: Data plug Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 No. of cable outlets: 1 Series: HC-M-RJ45-AD-I Shielded: yes Cable outlet: straight Positions/contacts: 8P8C Insulation characteristics Overvoltage category: I Degree of pollution: 2
Electrical properties	Rated voltage (III/3): 72 V (DC) Rated current: 1.75 A Contact resistance: < 20 mÃ© (Contact) < 100 mÃ© (shield) > 10 mÃ© (Wire Ã¢Ã¢¬Ã¢ IDC) 0.005 Ã© (Litz wires Ã¢Ã¢¬Ã¢ IDC) Insulation resistance: > 500 MÃ© Contact resistance per contact pair: < 20 Ã© Transmission characteristics (category): CAT6_A Transmission speed: 10 Gbps Power transmission: PoE++ Wave impedance: 100 Ã©
Dimensions	Width: 13.6 mm Height: 43.4 mm Length: 10.5 mm
Material specifications	Flammability rating according to UL 94: V0 Housing surface material: Ni Contact material: CuSn Contact surface material: Au/Ni Material for screw connection: PA Housing material: Metal
Cable/line	External cable diameter (): 5 mm ... 9 mm External cable diameter: 5 mm ... 9 mm Test voltage Core/Core: 1000 V Test voltage Core/Shield: 1500 V Wave impedance: 100 Ã©
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 70°C Ambient temperature (storage/transport): -40°C ... 70°C
Mounting	Mounting type: For field assembly Connection method: Insulation displacement connection
