Available
| Notes | General: Refer to the accessories list for the corresponding RJ45 connectors Connectors may be operated only when there is no load/voltage. |
| Mounting | Connection method: QUICKON fast connection |
| Product properties | Type: D7 RJ45 Product type: Contact insert with a fixed no. of positions Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 Application: Data Series: HC-Q Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Dimensions | Width: 21 mm Height: 35 mm Length: 21 mm |
| Connection data | Connection technology Connection in acc. with standard: IEC / EN Conductor connection Tightening torque: 0.5 Nm ... 0.8 Nm (Mounting screws for mounting in the HEAVYCON housing) |
| Electrical properties | Rated voltage (III/3): 50 V Rated surge voltage: 0.8 kV Rated current: 1 A Transmission characteristics (category): CAT5e |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Au Contact carrier material: PC Standards/regulations: PC: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 70°C |
| Standards and regulations | Testing Standards/regulations: PC: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3) |
