| Product properties | Product type: Test plug terminal block Number of positions: 4 Pitch: 8.2 mm Potentials: 4 |
| Electrical properties | Maximum power dissipation for nominal condition: 1.31 W |
| Connection data | Nominal cross section: 6 mm² 2.5 mm² Test socket torque: 0.5 Conductor cross section flexible: 0.5 mm² ... 2.5 mm² Conductor cross section, flexible [AWG]: 20 ... 14 (converted acc. to IEC) Nominal current: 20 A Maximum load current: 20 A Nominal voltage: 400 V |
| Dimensions | Width: 56.8 mm Height: 96.8 mm Depth: 98.2 mm Pitch: 8.2 mm |
| Material specifications | Color: gray Flammability rating according to UL 94: V0 Insulating material: PA |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (storage/transport): -25°C ... 60°C (for a short time, not exceeding 24Ãh, -60ðC to +70ðC) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 % |
