| Product properties | Product type: Plug Number of positions: 12 Pitch: 8.2 mm Potentials: 12 |
| Electrical properties | Maximum power dissipation for nominal condition: 1.31 W |
| Connection data | Nominal cross section: 6 mm² Nominal current: 24 A Maximum load current: 30 A Nominal voltage: 400 V |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/dcc04318320ce046964dcdcb3ad65876/-S204x204-FJPG Pitch: 8.2 mm |
| Material specifications | Color: gray Flammability rating according to UL 94: V0 Insulating material: PA |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (storage/transport): -25°C ... 60°C (for a short time, not exceeding 24Ãh, -60ðC to +70ðC) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 % |
