Non disponibile

Limit Switch, NEMA Type 4 and 13 Oiltight Construction, Non-Plug-In, Lever Type, Spring Return, High Operating Torque, 2-Circuit, CW and CCW operation, Whole Switch, Extended Temperature Operation

Cod. Articolo: 802T-HE Copia - Copy

Cod. Fornitore: 802T-HE Copia - Copy

ROCKWELL AUTOMATION

Caratteristiche Tecniche

Specifiche

Download

Caratteristiche Tecniche

SWITCH DATAEnergy RatingStandard EnergyPlug-In or NonPlug-In StyleNon-Plug-InSwitch ComponentsComplete SwitchActuation TypeLever Type, Spring Return, High Operating TorqueNumber of Circuits2-CircuitMode of OperationCW and CCW operationSafety SwitchNoTravel to Operate Contacts (Nominal)6°Torque to Operate Contacts (Max.)0.51N-m (4.5lb in)Travel to Reset Contacts (Max.)3°Maximum Travel50°MODIFICATIONSExtended TemperatureExtended Temperature -29°C to +121°C (-20°F to +250°F)OPERATING LEVER DATAOperating LeverOperating Lever Not SelectedAdditional DetailsTypeOiltight Limit Switches

Specifiche

Specifications
Type:Oiltight Limit Switches
Switch Data
Energy Rating:Standard Energy
Plug-In or NonPlug-In Style:Non-Plug-In
Switch Components:Complete Switch
Actuation Type:Lever Type, Spring Return, High Operating Torque
Number of Circuits:2-Circuit
Mode of Operation:CW and CCW operation
Safety Switch:No
Travel to Operate Contacts (Nominal):6°
Torque to Operate Contacts (Max.):0.51N-m (4.5lb in)
Travel to Reset Contacts (Max.):3°
Maximum Travel:50°
Modifications
Extended Temperature:Extended Temperature -29°C to +121°C (-20°F to +250°F)
Operating Lever Data
Operating Lever:Operating Lever Not Selected

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

limit-td001_-en-p.pdf
