| Product properties | Type: DIN rail module, two-section, divisible Product type: Base element Product family: PLUGTRAB PT Number of positions: 2 Surge protection fault message: none Wire pairs per module: 1 |
| Connection data | Connection method: Screw connection Screw thread: M3 Tightening torque: 0.5 Nm 0.8 Nm Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section rigid: 0.2 mm² ... 4 mm² Conductor cross section AWG: 24 ... 12 |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/ccdf98a6bdd749498f6c4126115c9c5f/-S204x204-FJPG Width: 17.7 mm Height: 90 mm Depth: 52 mm Horizontal pitch: 1 Div. Complete module width: 17.7 mm Complete module height: 90 mm Complete module depth: 65.5 mm |
| Material specifications | Color: Copper Flammability rating according to UL 94: V-0 |
| Mechanical properties | Mechanical data Open side panel: No |
| Protective circuit | Information technology Surge protection fault message: none |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 85°C |
| Standards and regulations | Standards/specifications: ENÃ61643-21/A1 Note: 2009 |
| Mounting | Mounting type: DIN rail: 35 mm |
