LEKFS32EA-900-R5CPF8

SMC LEKFS32EA-900-R5CPF8 - High Rigidity and High Precision - LEKFS. Product series: Slider Type, Ball Screw (24 VDC) - LE(K)FS, LE2FS, LEFSW, (25A/11-)LEFS, (11-)LEFG. Your everyday transfer solution for high loads: Transfer & position whatever the needs - Ball screw drive, the best for high loads and repeatable accurate positioning; Speed and ease your start-up and restarting - Battery-less type with absolute encoder allows restart from the last position; Boost your productivity - High-performance controller. Maximum speed of 1500 mm/s and maximum acceleration of 10000 mm/s²; Integrate seamlessly, operate effortlessly - Compatible with manifold controller, up to 16 axes. Automatic actuator detection; Accommodate it in any location - Variety of models to suit clean rooms, secondary battery manufacturing environments or IP65 enclosure rating needs. And much more: Body size: 16, 25, 32, 40; Compatible encoders: battery-less absolute, incremental; Step or servo motor; Available variations for non-standard environments: secondary batteries manufacturing, clean room; Horizontal/Vertical work load: up to 80/40 kg. Features: Body size: 16, 25, 32 and 40 mm; Stroke: 50 to 1200 mm; Acceleration: up to 3000 mm/s²; Speed: up to 1200 mm/s; Step motor type; Compatible encoder: battery-less absolute. Technical specifications: Series: LEKFS; Size: 32; Motor Mounting Position: In-line; Motor Type: E (Battery-less absolute, 24 VDC); Lead: A (Size 16: 10 mm, Size 25: 12 mm, Size 32: 16 mm, Size 40: 20 mm); Stroke: 900; Motor Option: Without Option; Seal Band Stopper: Standard; Actuator Cable Length: R5 (5); Controller: CPF (PROFINET® with STO Sub-Function); Controller Mounting: 8 (DIN Rail Mounting); Communication Plug Connector, I/O Cable: None; Maximum ambient temperature: 40 ºC; Minimum ambient temperature: 5 ºC; General power supply: 24 VDC ±10 %; Conform to the European RoHS Directive: Conform; Approvals: CE, UKCA; Impact/Vibration resistance: 50/20 m/s²; Actuation type: Ball screw (LEKFS#), Ball screw + Belt (LEKFS#R/L); Motor type: Step motor (Servo 24 VDC); Encoder: Battery-less absolute; Power supply: 123 W; Horizontal work load: 45 Kg; Vertical work load: 10 Kg; Speed: 16 - 410 mm/s; Max. Acceleration/deceleration: 3000 mm/s²; Operating humidity range: 90 % RH or less (No condensation); Positioning repeatability: ±0.01 (Lead H: ±0.02) mm; Lost motion: ? 0.05 mm; Lock: Holding force: 108 W; Guide type: Linear guide; Motor size: 56.4; Lock unit type: Non-magnetising lock; Lock unit power consumption: 5 W; Technical graph 1: 8655AA_graph3_en.jpg.
