ROCKWELL AUTOMATION 855PD-B24LEC1322
ROCKWELL AUTOMATION 855PD-B24LEC1322
ROCKWELL AUTOMATION 855PD-B24LEC1322
ROCKWELL AUTOMATIONNon disponibile

2 Ckt Panel Mount Alarm 2 Ckt Panel Moun

855PD Panel Mount Dual Circuit Alarms, Black Housing, 24V AC/DC, 65 mm, Light and Sound Combination, Sounder, Green Lens, 22.5 mm
Cod. Articolo: 855PD-B24LEC1322
Cod. Fornitore: 855PD-B24LEC1322
ROCKWELL AUTOMATION


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Download
Caratteristiche Tecniche
Degree of protection (NEMA)4X
Degree of protection (IP)IP65
Operating temperature-25 °C
Storage temperature-25 °C
Loudness103 dB
Lamp typeLED
Nominal voltage24 V
Nominal current95 mA @ 24V AC/DC, 50/60 Hz
Sound level, maxAverage: 103 dB(A) @ 1 m (3.3 ft)
With contactNo
Frequency sound signal3.3 kHz
Continuous sound typeYes
Supply voltage range±10%
Turn-ON leakage current≥3 mA
Sound level, min<85 dB
Sound level adjustmentStepless
Sound selectionExternally by terminal connection
Suitable for ceiling mountingNo
Colour housingBlack
Lens colorGreen
Second lens color selectionGreen
First lens color/sound selectionSound
Lens materialPolycarbonate
Base materialPolycarbonate, black
Mounting hole size22.5 mm round mounting hole
TerminalsPlug-in terminal block, up to 2.5 mm2 (14 AWG), IP2X
MountingCentral mounting for bore holes 22 mm or 30.5 mm with hole adapter kit
Height82 mm
Weight85 g
List of degrees of protection (NEMA)4, 4X, 13
Size65 mm diameter
Mounting nut torque1.7 Nm
FunctionCombined sounder with LED beacon
