800F PB, 22mm DeviceNet Station, 3 Hole Station Legend Frames, Vertical, Pilot Light, Red, Flush, Green with START Text, Extended, Red with STOP Text, None, None, No External Input/Output

800F PB,22mm DeviceNet Station,3 Hole Station Legend Frames,Vertical,Pilot Light,Red,Flush,Green with START Text,Extended,Red with STOP Text,None,None,No External Input/Output

Cod. Articolo: 800F-VBJ4AABB Copia - Copy

Cod. Fornitore: 800F-VBJ4AABB Copia - Copy

ROCKWELL AUTOMATION

Number of operators	3
Operator mounting hole dimension	22.5 mm
Operator mechanical design life (cycles, min.)	1.0E7
Operator 2 legend text	START
Operator 3 legend text	STOP
Hazardous location rating	No
Contact block termination tightening torque	0.7 to 0.9 Nm
I/O version	No external input/output
Station type	800F assembled stations with Devicenet
Enclosure mounting	Vertical (Selector Switches in a vertical mount enclosure are mounted with a horizontal orientation)
Contact block termination wire range	spring clamp termination: #18...14 AWG (0.75...1.5 mmÃ²) one per spring clamp, two spring clamps per terminal
Termination style	Screw
Contact block electrical design life (cycles, at max. load)	1000000
Vibration	10 G maximum
Shock	25 G (contact fragility)/100 G (no damage)
Operator 1 color	Red
Operator 2 color	Green
Operator 3 color	Red
Operator 4 color	None
Operator type 2	Non-illuminated flush button
Operator type 3	Non-illuminated extended button
Operator type 4	None
Operator type 1	Pilot light
Operating temperature	-25 Ã°C
Storage temperature	-40 Ã°C
Humidity	Ã¢Ã¢°¤95% RH from 25...60 Ã°C (77...140 Ã°F)
Contact block operational voltage, max	600V AC (A600, Q600) - screw termination
Contact block utilization category (DC)	DC 13 to IEC/EN 60947-5-1 and UL 508, 17V, 5 mA minimum
Contact block utilization category (AC)	AC-15 (A600, Q600): screw termination, AC-15 (A300, Q300): spring clamp termination
Contact block thermal current rating	10 A
Certifications	ABS, CCC, CE, CSA, EAC, GOST, UL

Accedi ai servizi

Entra nella tua area riservata

Accedi ai servizi

800F PB, 22mm DeviceNet Station, 3 Hole Station Legend Frames, Vertical, Pilot Light, Red, Flush, Green with START Text, Extended, Red with STOP Text, None, None, No External Input/Output

Altri prodotti correlati

800F PB, 22mm DeviceNet Station, 3 Hole Station, Vertical, Illuminated Flush, Blue, Illuminated Flush, Amber, Illuminated Flush, Green, None, None, No External Input/Output
Cod. Articolo: 800F-VED6D0D3

800F 1 Hole Enclosure, Gray Plastic, KnockoutType- Metric
Cod. Articolo: 800F-1PM2M92

800F PB, 22mm DeviceNet Station, 2 Hole Station, Vertical, Hole Plug, Gray, Illuminated Flush, Amber, None, None, None, None, No External Input/Output
