Number of contacts as normally closed contact	1
Number of contacts as normally open contact	1
With status indication	No
Type of electric connection	Other
Utilization category	N600/DC-13
Switching current, min	5 mA @ 5V DC
Two-circuit 5-pin mini M12 connector current	2.5 A @ 300V DC
Auxiliary contacts	1NO (with 2 NC)
Contact current rating (Ie)	6 A @ 120V AC (Ue)
Thermal current (Ith)	10 A
Actuation speed, min	100 mm/min
Actuation speed, max	250 mm/s
Rated impulse withstand voltage	2500 V
Actuation frequency, max	6000 ops/hr
Rated insulation voltage	600V AC
Suitable for safety functions	Yes
Forced opening	Yes
Degree of protection (NEMA)	1
Material housing	Metal
Degree of protection (IP)	IP66
Number of pins	5-pins
Contact type	Snap acting
Enclosure color	Red
Mounting	2 x M5, any position
Body style	30 mm large metal body
Width	40 mm
Height	118 mm
Actuator type	Roller plunger
Mechanical life operations	10000000 operations per hour
Housing material	Die-cast alloy
Connection type	Mini
Construction type housing	Cuboid
Depth	43 mm
Actuator material	Various polymers and metals
Operating temperature	-25 Ã°C
Safety contacts	1 NC snap acting, 2 NC, 3 NC or 4 NC slow acting
Pollution degree	3
Shock	IEC 60068-2-7 (30 Gn 3 pulses per axis)
Vibration	IEC 60068-2-6 (10...55 Hz, 0.35 mm amplitude)

Accedi ai servizi

Bulletin 440P, Large Metal IEC, Full Switch (Head <(>&<)> Body), Roller Plunger, Snap Acting, 1NO 1NC Circuits, 5-Pin Mini Quick Disconnect
