ROCKWELL AUTOMATION 440P-CDPM12B

ROCKWELL AUTOMATION 440P-CDPM12B

Non disponibile

Safety Limit Switches, Small Plastic IEC, Full Sw Head & Body, Top Push Rod, 3 Circuits, Conduit Entry, Make Before Break, 1 Normally Open Contact, 2 Normally Closed Contacts, Standard Contacts, -25C Low Temp Limit, 65C High Temp Limit, Spring Return,

Safety Limit Switch, 22mm Plastic, Dome Plunger, 2 N.C., 1 N.O., MBB, M20 Conduit

Cod. Articolo: 440P-CDPM12B

Cod. Fornitore: 440P-CDPM12B

ROCKWELL AUTOMATION

Caratteristiche Tecniche

Caratteristiche Tecniche

Number of contacts as normally closed contact	2
Number of contacts as normally open contact	1
With status indication	No
Type of electric connection	Other
Utilization category	Q600/DC-13
Switching current, min	25 mA @ 5V DC
Auxiliary contacts	1NO (with 2 NC)
Contact current rating (Ie)	6 A @ 120V AC (Ue)
Thermal current (Ith)	10 A
Actuation speed, min	100 mm/min
Actuation speed, max	250 mm/s
Actuation frequency, max	6000 ops/hr
Rated insulation voltage	600V AC
Suitable for safety functions	Yes
Forced opening	Yes
Degree of protection (NEMA)	1
Material housing	Plastic
Degree of protection (IP)	IP66
Contact type	Make before break
Enclosure color	Red
Mounting	2 x M4, any position
Body style	22 mm small plastic body
Width	31 mm
Height	79 mm
Actuator type	Dome plunger
Mechanical life operations	10000000 operations with no electrical load
Housing material	UL approved glass-filled polybutylene terephthalate
Connection type	M20 conduit
Construction type housing	Cuboid
Depth	31 mm
Actuator material	Various polymers and metals
Operating temperature	-25 Ã°C
Safety contacts	1 NC snap acting, 2 NC, 3 NC or 4 NC slow acting
Pollution degree	3
Shock	IEC 60068-2-7 (30 Gn 3 pulses per axis)
Vibration	IEC 60068-2-6 (10...55 Hz, 0.35 mm amplitude)
