ROCKWELL AUTOMATION 1763-L16BWA
ROCKWELL AUTOMATION 1763-L16BWA
ROCKWELL AUTOMATIONDisponibile

1763 MicroLogix 1100 System, MicroLogix 1100, 120/240V ac power, (10) 24V dc digital inputs, (2) 10V analog inputs, (6) relay outputs

1763 MicroLogix 1100 System, MicroLogix 1100, 120/240V ac power, (10) 24V dc digital inputs, (2) 10V analog inputs, (6) relay outputs
Cod. Articolo: 1763-L16BWA
Cod. Fornitore: 1763-L16BWA
ROCKWELL AUTOMATION


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Specifiche
Descrizione
Caratteristiche Tecniche
Features
Compatible with 1762 MicroLogix Expansion I/O modules (up to four modules per controller)
Lets you access, monitor and program from any Ethernet connection
Provides 8 KB memory (4 KB user program with 4 KB user data)
Contains isolated RS-232/RS-485 combination port for serial and networked communication
Provides embedded web server so you can configure controller data to be displayed as a web page
Supports up to 144 digital I/O points
Lets you monitor and modify controller data through an embedded LCD screen
Supports on-line editing
Includes built-in 10/100 MBps EtherNet/IP™ port for peer-to-peer messaging
Accessories
1585J-M8TBJM-1M9
Specifiche
Specifications
Sub Brand:MicroLogix 1100
Type:Controller
Special Features:Built-in RTC, Online Editing, 1 HSC, 2 PTO/PWM, Up to 4 Expansion I/O
Standard:c-UL-us CL1DIV2, CE, C-Tick, KCC
Number Of Channels:10 I/P, 6 O/P
Input Signal:24 V DC
Output Signal:Relay
Communication:DF1, DH-485, Modbus RTU, ASCII, EtherNet/IP messaging
Enclosure:IP20
Display:Yes
Memory:8 KB
Interface:Ethernet Port and Isolated RS-232/RS-485 combo port
Power Supply:24V DC
Mounting:DIN Rail, Panel Mount
Height:90
Width:110
Depth:87
Operating Temperature:-20... 60 °C (-4...140 °F)
Embedded Analog:(2) Analog Voltage I/P
Controllers
Controllers:MicroLogix 1100, 120/240V ac power, (10) 24V dc digital inputs, (2) 10V analog inputs, (6) relay outputs
Accessory Products
Network Media:Male RJ45 to Male RJ45 Patchcord, Unshielded Twisted Pair, Teal TPE Cable, 1.9 m
Descrizione
MicroLogix 1100, 120/240V ac power, (10) 24V dc digital inputs, (2) 10V analog inputs, (6) relay outputs
