| Nominal value output voltage 1 | 12 V |
| Secondary voltage adjustable | Yes |
| Max. output current 1 | 10 A |
| Nominal value output current 1 | 10 A |
| Power output | 120 W |
| Voltage type of supply voltage | AC/DC |
| 1st secondary output voltage | 12 V |
| Rated supply voltage at AC 50 Hz | 100 V |
| Rated supply voltage at AC 60 Hz | 100 V |
| Rated supply voltage at DC | 110 V |
| Power reserves | 20 % |
| DC OK relay contact | Yes |
| Input inrush current limiter | NTC |
| Power factor | 0.91 typical |
| Output current range | 10 to 8 A |
| External input fuse, min | B-6 A or C-6 A |
| Power losses | 7.7 W typical |
| Derating | 3 W/ðC |
| Efficiency | 94 % typical |
| Input inrush current | 5 A/6 A |
| Output voltage stabilized | Yes |
| Rail mounting possible | Yes |
| Stabilized | Yes |
| Height | 124 mm |
| Depth | 102 mm |
| Direct mounting possible | No |
| Width | 32 mm |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Screw connection |
| MTBF | 732 kh (+40 ðC, SN29500) |
| Wall mounting possible | Yes |
| Ripple and noise, max | 50 mV |
| Operating temperature | -25 ðC |
| Lifetime, min | 110 kh (+40 ðC) |
| Weight | 440 g |
