Disponibile

Contactor, 37 A, 200-220V 50 Hz / 208-240V 60 H, AC, 3 Normally Open Poles, 208-240V AC 60 Hz, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load

Contactor,37 A,200-220V 50 Hz / 208-240V 60 H,AC,3 Normally Open Poles,208-240V AC 60 Hz,No Contact Configuration,Single Pack,Line Side Coil Termination,Screw Terminals,Motor Load

Cod. Articolo: 100-C37L00

Cod. Fornitore: 100-C37L00

ROCKWELL AUTOMATION

Specifiche

Download

Specifiche

Specifications
Connection:Screw Terminals
3-Phase kW (50 Hz) 230V Rating:11
3-Phase kW (50 Hz) 400V/415V Rating:18.5/20
3-Phase kW (50 Hz) 500V Rating:20
3-Phase kW (50 Hz) 690V Rating:18.5
3-Phase HP (60 Hz) 200V Rating:10
3-Phase HP (60 Hz) 230V Rating:10
3-Phase HP (60 Hz) 460V Rating:25
3-Phase HP (60 Hz) 575V Rating:30
Contactor Data
Terminal Type:Screw Terminals
Rated Operating Current, AC-3:37A
Coil Voltage:208-240V 60Hz
No. of Poles:3 Poles
Coil Termination:Line Side
Contact Configuration:0 N.O. 0 N.C. Auxiliary Contact Configuration
Package Quantity:1
Application Data
Electrical Standards:UL
Load Data [Optional]
Utilization Category:AC-3 Squirrel-cage motor starting and stopping
Life Data [Optional]
Actual Life:Actual Life Cannot be Calculated (more information)...
Terminal Marking Positions Used
100-C or 104-C Contactor:None
Front Mounted Auxiliary Contact:None
Left Side Auxiliary Contact:None
Right Side Auxiliary Contact:None
Interlock:None

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

100-td013_-en-p.pdf
