| Product properties | Product type: Circular connector (cable-side) Thread type: M23 |
| Material specifications | Flammability rating according to UL 94: V0 |
| Connector | Insulating body Coding: N Insertion/withdrawal cycles: 100 Connection method: Solder cup Contact switching type: Socket Application: Signal Number of positions: 19 Direction of rotation: Standard Connection profile: 16+3 Contact diameter Power contacts: 1.5 mm Litz wire cross-section Power contacts min.: 0.08 mm² Litz wire cross-section Power contacts max.: 1 mm² Rated current Power contacts: 10 A Rated voltage: 48 VAC 74 VDC Rated surge voltage: 1.5 kV Overvoltage category: III Degree of pollution: 3 Contact diameter Signal contacts: 1 mm Litz wire cross-section Signal contacts min.: 0.08 mm² Litz wire cross-section Signal contacts max.: 1 mm² Nominal current per signal contact: 8 A Contact diameter Data contacts: 1.5 mm Housing Housing material: Metal Type of locking: Screw locking mechanism Pg screw connection: none Degree of protection (plugged in): IP65 IP67 Thread type: M23 |
