PHOENIX CONTACT 1594049
PHOENIX CONTACT 1594049
PHOENIX CONTACTNon disponibile

RC-06S1N8A8004 - Cable connector

M23, Cable connector, straight, shielded: no, Screw locking mechanism, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Socket, Crimp connection, cable diameter range: 7.5 mm ... 9.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1240444
Cod. Articolo: 1594049
Cod. Fornitore: 1594049
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Download
Caratteristiche Tecniche
NotesGeneral: Order crimp contacts Ø 2 mm separately
Product propertiesProduct type: Circular connector (cable-side)
ConnectorInsulating body
Note: Order information: Order crimp contacts Ø 2 mm separately
Coding: N
Connection method: Crimp connection
Contact switching type: Socket
Application: Signal
Number of positions: 6
Direction of rotation: Standard
Connection profile: 6
Contact diameter Power contacts: 2 mm
Rated current Power contacts: 20 A
Rated voltage: 48 VAC
74 VDC
Rated surge voltage: 1.5 kV
Overvoltage category: III
Degree of pollution: 3
Housing
Order information:: Order contact inserts separately
Housing material: Metal
Type of locking: Screw locking mechanism
Pg screw connection: none
Degree of protection (plugged in): IP65
IP67
IP68
Thread type: M23
Seal
External cable diameter: 7.5 mm ... 9.5 mm
