PHOENIX CONTACT 1590439
PHOENIX CONTACT 1590439
PHOENIX CONTACTNon disponibile

HC-28S1N12WA00 - Device connector front mounting

Device connector front mounting, straight, Screw locking mechanism, M27, contact connection type: Socket, Radial O-ring, 4x Ø 3.2, shielded: yes, degree of protection: IP67, number of positions: 28, connection method: Solder connection, series: HC, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1240163
Cod. Articolo: 1590439
Cod. Fornitore: 1590439
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Download
Caratteristiche Tecniche
MountingMounting: 4x Ø 3.2
Connection method: Solder connection
Product propertiesProduct type: Circular connectors (device side)
Number of positions: 28
Application: Signal
Series: HC
Shielded: yes
Coding: N
Thread type: M27
Material specificationsFlammability rating according to UL 94: V0
Seal material: FPM or NBR or EPDM
Housing material: Turned parts: copper zinc alloy (CuZn), die-cast parts: zinc (GD-Zn)
Metal
Insulator material: PA66
Contact material: CuZn
Contact surface: Nickel-plated, gold coating
Gasket and O-ring material: FPM
Electrical propertiesContact
Contact diameter: 1 mm
Min. cross section: 0.08 mm²
Max. cross section: 1 mm²
Max. current: 8 A
Nominal voltage UN: 48 VAC 74 VDC
Overvoltage category: III
Degree of pollution: 3
Rated surge voltage: 1.5 kV
Connection dataConductor connection
Connection method: Solder connection
Contact connection type: Socket
Mechanical propertiesMechanical data
Insertion/withdrawal cycles: 50
ConnectorType: straight
Direction of rotation: Standard
Environmental and real-life conditionsAmbient conditions
Degree of protection: IP67
Ambient temperature (operation): -20°C ... 125°C
Altitude: 2000 m
