| Mounting | Mounting type: Front mounting M12 x 1 With locking nut Assembly instructions: With locking nut Connection method: Solder pins |
| Product properties | Product type: Circular connectors (device side) Number of positions: 4 Shielded: yes |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Cu alloy Contact surface material: Gold over nickel Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Nominal voltage UN: 30 V Nominal current IN: 1 A Transmission characteristics (category): CAT7, for USB 2.0 (480 Mbps) |
| Connection data | Conductor connection Connection method: Solder pins |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Connector | Connection 1 Head design: Socket Head cable outlet: straight Head thread type: M12 Head locking type: SPEEDCON |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -25°C ... 85°C (Plug / socket) |
