| Notes | General: The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration. |
| Mounting | Mounting type: Front mounting Connection method: Individual wires |
| Product properties | Product type: Circular connectors (device side) Sensor type: Power Number of positions: 4 Shielded: no Coding: T Thread type: M12 Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: V0 Seal material: FKM Contact material: CuZn Contact surface material: Au Contact carrier material: PA Material for screw connection: Zinc die-cast, nickel-plated Conductor material: Bare Cu litz wires |
| Electrical properties | Rated surge voltage: 1.5 kV 1.5 kV AC/DC Nominal voltage UN: 63 VDC Nominal current IN: 12 A |
| Connection data | Conductor connection Connection method: Individual wires Contact connection type: Socket Conductor cross section: 1.31 mm² Tightening torque: 0.8 Nm 1.3 Nm |
| Connector | Connection 1 Head design: Socket Head cable outlet: straight Coding: T Connection 2 Head design: free cable end |
| Cable/line | Cable length: 1.5 m Cable type: UL/cUL stranded hook-up wire Signal type/category: Power Wire diameter incl. insulation: 2 mm Single wire, color: black, brown, blue, white Cable cross section: 1.31 mm² Conductor material: Bare Cu litz wires AWG signal line: 16 Material wire insulation: mPPE Halogen-free: yes Flame resistance: in acc. to UL1581 VW1 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65/IP67 |
| Standards and regulations | Flame resistance: in acc. to UL1581 VW1 M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-111 Note: In line with |
