CLT-10P/2-2-12V-I-P - Surge protection plug

Surge protection plug, directly pluggable on 2 terminal blocks, with integrated status indicator on the module for a 2-wire floating signal circuit. Nominal voltage: 12VDC

Cod. Articolo: 1088569 Copia - Copy

Cod. Fornitore: 1088569 Copia - Copy

PHOENIX CONTACT

Product properties	IEC test classification: C1 C2 C3 D1 Type: DIN rail module, two-section, divisible Product type: Surge protection for MCR technology Product family: CLIXTRAB Insulation characteristics Overvoltage category: III Pollution degree: 3
Electrical properties	Nominal voltage U_N: 12 VÃDC
Connection data	Connection method: pluggable
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/817dc5e597a32e48ba12687425ec0495/-S204x204-FJPG Width: 10.3 mm Height: 53.25 mm Depth: 81.9 mm
Material specifications	Flammability rating according to UL 94: V-0 Insulating material: PA 6.6+GV 20 % Housing material: PA 6.6+GV 20Ã%
Mechanical properties	Mechanical data Open side panel: No
Protective circuit	Direction of action: Line-Line & Line-Earth Ground Maximum continuous voltage U_C: 15 VÃDC 10 VÃAC Rated current: 600 mA (80Ã°C) Operating effective current I_C at U_C: Ã¢Ã¢°¤ 150 ÃµA Residual current I_PE: Ã¢Ã¢°¤ 1 ÃµA Total discharge current I_total (8/20)ÃÃµs: 10 kA Voltage protection level U_p (line-line): Ã¢Ã¢°¤ 40 V (C1 - 700 V/350 A) Ã¢Ã¢°¤ 35 V (C3 - 100ÃA) Voltage protection level U_p (line-earth): Ã¢Ã¢°¤ 900 V (C1 - 2ÃkV / 1ÃkA) Ã¢Ã¢°¤ 900 V (C2 - 10 kV / 5 kA) Ã¢Ã¢°¤ 1050 V (C3 - 100ÃA) Response time t_A (line-line): Ã¢Ã¢°¤ 1 ns Response time t_A (line-earth): Ã¢Ã¢°¤ 100 ns Input attenuation aE, sym.: typ. 0.3 dB (Ã¢Ã¢°¤Ã8,5ÃMHz / 150ÃÃ©) Input attenuation aE, asym.: typ. 0.3 dB (Ã¢Ã¢°¤Ã14,5ÃMHz / 150ÃÃ©) Cut-off frequency fg (3ÃdB), sym. in 150ÃÃ© system: typ. 60 MHz Cut-off frequency fg (3ÃdB), asym. (signal ground) in 150ÃÃ© system: typ. 60 MHz Capacity (Core-Core): typ. 45 pF Capacity (line-signalground): typ. 30 pF Surge protection fault message: optical Max. required back-up fuse: 630 mA (T) Impulse durability (line-line): C1 - 700ÃV / 350ÃA C3 - 100ÃA Impulse durability (line-earth): C1 - 2ÃkV / 1ÃkA C2 Ã¢Ã¢¬Ã¢ 10 kV / 5 kA C3 - 100ÃA D1 - 1,25ÃkA Pulse reset time (line-earth): Ã¢Ã¢°¤ 30Ãms
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 80°C Ambient temperature (storage/transport): -40°C ... 80°C Altitude: Ã¢Ã¢°¤ 2000 m (amsl) Permissible humidity (operation): 5 % ... 95 % Shock (operation): 5g (Half-sine / 11 ms / 3x Ã±X, Ã±Y, Ã±Z) 10g (Half-sine / 8Ãms / 3x Ã±X, Ã±Y, Ã±Z) 5g (Half-sine / 30Ãms / 3x Ã±X, Ã±Y, Ã±Z) Vibration (operation): 0,58g (5 ... 150ÃHz / 5Ãh / X, Y, Z) 1g (5 ... 2000ÃHz / 5Ãh / X, Y, Z)
Standards and regulations	Standards/specifications: IEC 61643-21 ENÃ61643-21 Note: 2000 + corrigendum 2001 + A1:2008, modified + A2:2012 2001 + A1:2009 + A2:2013
Mounting	Mounting type: on base element
