VAL-MS 1500DC-PV/2+V-FM - TypeÂ 2 surge arrester

Surge protective device for 2-pos. isolated and grounded 1,500VDC PV systems, for DIN rail mounting, 3-pos. base element with remote indication contact, three pluggable temperature-monitored protective elements, status message on each plug.

Cod. Articolo: 1033725 Copia - Copy

Cod. Fornitore: 1033725 Copia - Copy

PHOENIX CONTACT

Notes	General Note: The device is intended for touch proof installation in a housing. Ensure that there is a gap of at least 8 mm between the active and grounded parts in the connection area.
Product properties	IEC test classification: PV II PV T2 EN type: T2 IEC power supply system: DC Type: DIN rail module, two-section, divisible Distance between live and grounded parts: 8 mm Product type: PV arrester Product family: VALVETRAB MS Installation location: Interior Installation location of the disconnect device: Internal Accessibility: Accessible Connection configuration: Y configuration SPD failure behavior: OCFM (Open-Circuit Failure Mode) Surge protection fault message: Optical, remote indicator contact Insulation characteristics Overvoltage category: III Pollution degree: 2
Electrical properties	Indicator/remote signaling Connection name: Remote fault indicator contact Switching function: Changeover contact Operating voltage: 30 VÃAC 30 VÃDC Operating current: 1 A AC 1 AÃDC
Connection data	Connection method: Screw connection Fork-type cable lug Screw thread: M5 Tightening torque: 3 Nm (1.5Ãmm² ... 16Ãmm²) 4.5 Nm (25Ãmm²Ã...Ã35Ãmm²) Stripping length: 16 mm Conductor cross section flexible: 1.5 mm² ... 25 mm² 1.5 mm² ... 16 mm² Conductor cross section rigid: 1.5 mm² ... 35 mm² Conductor cross section AWG: 15 ... 2 Remote fault indicator contact Connection method: Plug-in/screw connection via COMBICON Screw thread: M2 Tightening torque: 0.25 Nm Stripping length: 7 mm Conductor cross section flexible: 0.14 mm² ... 1.5 mm² Conductor cross section rigid: 0.14 mm² ... 1.5 mm² Conductor cross section AWG: 28 ... 16
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/0e4a0832d4206348bed6ca2ea11b5b69/-S204x204-FJPG Width: 53.4 mm Height: 98.7 mm Depth: 65.7 mm Horizontal pitch: 3 Div.
Material specifications	Flammability rating according to UL 94: V-0 CTI value of material: 600 Insulating material: PA 6.6-FR PBT-FR Material group: I Housing material: PA 6.6-FR PBT-FR
Mechanical properties	Mechanical data Open side panel: No
Protective circuit	Mode of protection: (L+) - (L-) (L+) - PE (L-) - PE Direction of action: (L+)-PE & (L-)-PE & (L+)-(L-) Rated load current I_L: 80 A Residual current I_PE: Ã¢Ã¢°¤ 350 ÃµA DC Ã¢Ã¢°¤ 600 ÃµA AC Standby power consumption P_C: Ã¢Ã¢°¤ 250 mVA Nominal discharge current I_n (8/20) Ãµs: 15 kA Maximum discharge current I_max (8/20) Ãµs: 30 kA Total discharge current I_total(8/20)ÃÃµs: 30 kA Voltage protection level U_p: Ã¢Ã¢°¤ 5 kV Residual voltage U_res: Ã¢Ã¢°¤ 3.8 kV (at 3ÃkA) Ã¢Ã¢°¤ 4.1 kV (at 5 kA) Ã¢Ã¢°¤ 4.4 kV (at 10 kA) Ã¢Ã¢°¤ 5 kV (at 15 kA) Ã¢Ã¢°¤ 5.3 kV (at 20 kA) Ã¢Ã¢°¤ 5.7 kV (at 30 kA) Ã¢Ã¢°¤ 6 kV (at 40 kA) Response time t_A: Ã¢Ã¢°¤ 25 ns PV protective circuit Connection configuration: Y configuration SPD failure behavior: OCFM (Open-Circuit Failure Mode) Protective circuit DC voltage side (DC) Open circuit voltage U_OCSTC: Ã¢Ã¢°¤ 1250 VÃDC Maximum discharge current I_max (8/20) Ãµs: 30 kA Response time t_A: Ã¢Ã¢°¤ 25 ns Total discharge current I_total(8/20)ÃÃµs: 30 kA Nominal discharge current I_n (8/20) Ãµs: 15 kA Rated load current I_L: 80 A Continuous operating current I_CPV: < 350 ÃµA Maximum continuous operating voltage U_CPV: 1500 VÃDC Short-circuit current rating I_SCPV: 2000 A Residual voltage U_res: Ã¢Ã¢°¤ 3.8 kV (at 3ÃkA) Ã¢Ã¢°¤ 4.1 kV (at 5 kA) Ã¢Ã¢°¤ 4.4 kV (at 10 kA) Ã¢Ã¢°¤ 5 kV (at 15 kA) Ã¢Ã¢°¤ 5.3 kV (at 20 kA) Ã¢Ã¢°¤ 5.7 kV (at 30 kA) Ã¢Ã¢°¤ 6 kV (at 40 kA) Residual current I_PE: Ã¢Ã¢°¤ 350 ÃµA DC Ã¢Ã¢°¤ 600 ÃµA AC Voltage protection level U_p: Ã¢Ã¢°¤ 5 kV Standby power consumption P_C: Ã¢Ã¢°¤ 250 mVA Additional technical data Maximum discharge current I_max (8/20) Ãµs: 40 kA Nominal discharge current I_n (8/20) Ãµs: 20 kA (4x (5x I_nÃ\|Ã120 s)Ã\|Ã30 min))
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 (only when all terminal points are used) Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C Altitude: Ã¢Ã¢°¤ 3000 m (amsl) Permissible humidity (operation): 5 % ... 95 % Shock (operation): 30g (Half-sine / 11 ms / 3x Ã±X, Ã±Y, Ã±Z) Vibration (operation): 5g (5-500 Hz/2.5 h/XYZ)
Approvals	UL specifications Maximum continuous operating voltage MCOV: 1500 VÃDC Short-circuit current rating (SCCR): 50 kA Voltage protection rating VPR: 4 kV Nominal discharge current I_n: 10 kA Mode of protection: (DC+) - (DC-) (DC+) - G (DC-) - G Nominal voltage: 1500 VÃDC Power distribution system: DCÃPV SPD Type: 1CA UL indicator/remote signaling Operating voltage: 30 VÃAC DC operating voltage: 30 VÃDC AC operating current: 1 A AC DC operating current: 1 AÃDC UL connection data Tightening torque: 30 lb_f-in. Conductor cross section AWG: 14 ... 2
Standards and regulations	Standards/specifications: ENÃ61643-31 IEC 61643-31 Note: 2019 2018
Mounting	Mounting type: DIN rail: 35 mm
