Specifiche
Safety data
Input voltage Ui:32 V (IIB (C/D))
Max. output voltage Uo:Uin (spur)
Max. output current Io:56 mA (spur)
Max. output power Po:1.792 W
Max. external capacitance Co:80 nF
Additional text:spur
Group:IIC/IIB
Max. external inductivity Lo:0.26 mH
ATEX:Sira 13ATEX4247X; II 3(3)G Ex nA [ic] IIC T4 Gc, Entity/FISCO ic spurs Ex nA [nL] IIC T4 Gc; II 3G Ex ic IIC T4 Gc, FISCO ic
IECEx:IECEx SIR 13.0089X; Ex nA [ic] IIC T4 Gc, Entity/FISCO ic spurs; Ex nA [nL] IIC T4 Gc; Ex ic IIC T4 Gc, FISCO ic
UL, USA:Class I, Zone 2; AEx nA[ic] IIC T4, Entity/FISCO spurs Class I, Div. 2, Groups A, B, C, D; T4
CSA, USA/Canada:Class I, Div. 2, Groups A, B, C, D; Ex nA [nL] IIC T4; Class I, Zone 2, AEx nA [nC] IIC T4
Standards and Regulations
Type of test:Corrosive resistance in acc. to ANSI-ISA 71.04-1985 - Severity level G3
Standards/regulations:Ring wave noise immunity in acc. with IEC 61000-4-12
Designation:Standards/regulations
Standards/regulations:Dry heat in acc. with IEC 61131-2
Standards/regulations:Damp heat in acc. with IEC 61131-2
Standards/regulations:Shock and vibration in acc. with EN 61131-2 and EN 50178
Standards/regulations:IEC 61158-2
Standards/regulations:EN 60079-0:2011; EN 60079-11:2012; EN 60079-15:2005; EN 60079-15:2010
Standards/regulations:IEC 60079-0:2011; IEC 60079-11:2011; IEC 60079-15:2005; IEC 60079-15:2010
Flammability rating according to UL 94:V0
Shock:30g, 11 ms
Vibration (operation):5g, 10 Hz - 150 Hz
Conformance:CE-compliant, additionally EN 61326
UL, USA:ANSI/UL 61010-1
Fieldbus Foundation:FF-846
Group:IIC/IIB
ATEX:Sira 13ATEX4247X; II 3(3)G Ex nA [ic] IIC T4 Gc, Entity/FISCO ic spurs Ex nA [nL] IIC T4 Gc; II 3G Ex ic IIC T4 Gc, FISCO ic
IECEx:IECEx SIR 13.0089X; Ex nA [ic] IIC T4 Gc, Entity/FISCO ic spurs; Ex nA [nL] IIC T4 Gc; Ex ic IIC T4 Gc, FISCO ic
UL, USA:Class I, Zone 2; AEx nA[ic] IIC T4, Entity/FISCO spurs Class I, Div. 2, Groups A, B, C, D; T4
CSA, USA/Canada:Class I, Div. 2, Groups A, B, C, D; Ex nA [nL] IIC T4; Class I, Zone 2, AEx nA [nC] IIC T4
Dimensions
Caption:Image shows FB-12SP
Width:254.1 mm
Height:112.5 mm
Depth:83.5 mm
Interfaces
Interface 1:Foundation Fieldbus and PROFIBUS PA Segment
No. of ports:8
Connection method:Pluggable COMBICON screw connection for each spur
Termination resistor:100 Ω (external removable plug)
Termination resistor:100 Ω, external removable plug included
Conductor cross section solid min.:0.2 mm²
Conductor cross section solid max.:2.5 mm²
Conductor cross section flexible min.:0.2 mm²
Conductor cross section flexible max.:2.5 mm²
Conductor cross section AWG min.:24
Conductor cross section AWG max.:12
Output nominal voltage:⤠32 V (each spur)
Output current:38 mA
Inductance Li:4 µH
Max. output voltage Uo:Uin (spur)
Ambient conditions
Ambient temperature (operation):-50 °C - 90 °C
Ambient temperature (storage/transport):-50 °C - 90 °C
Permissible humidity (operation):5 % - 95 % (non-condensing)
Permissible humidity (storage/transport):non-condensing
Altitude:2000 m
Degree of protection:IP20
Power supply
Supply voltage range:10.6 V DC - 32 V DC (input on trunk line side)
Typical current consumption:6.5 mA
Conductor cross section flexible max.:0.20 mm²
Conductor cross section flexible min.:2.50 mm²
Conductor cross section solid max.:0.20 mm²
Conductor cross section solid min.:2.50 mm²
Max. AWG conductor cross section, flexible:12
Min. AWG conductor cross section, flexible:24
Conductor cross section AWG max.:12
Conductor cross section AWG min.:24
Environmental Product Compliance
REACh SVHC:Lead 7439-92-1
