PHOENIX CONTACT 0830768
PHOENIX CONTACT 0830768
PHOENIX CONTACTNon disponibile

US-TML (104X3,8) - Marker for terminal blocks

Marker for terminal blocks, Card, white, unlabeled, can be labeled with: BLUEMARKIDCOLOR, BLUEMARKID, THERMOMARK PRIME, THERMOMARK CARD 2.0, THERMOMARK CARD, mounting type: adhesive, lettering field size: 104x3.8mm, Number of individual labels: 22
Cod. Articolo: 0830768
Cod. Fornitore: 0830768
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Download
Caratteristiche Tecniche
Product propertiesProduct type: Terminal marking
Type: Label
Marking
Number of individual labels: 22
Number of individual labels per row: 1
Identification technology: Thermal transfer for sheets and cards, UV LED technology
DimensionsWidth: 3.8 mm
Length: 104 mm
Material specificationsRoHS compliant: yes
Adhesive: Acrylic
Color: white
Material: Polyester
Components: free from silicone and halogen
Environmental and real-life conditionsTest for substances that would hinder coating with paint or varnish
Result: Test passed
UV resistance
Specification: ISO4892-2:2013-03 (following)
Result: Test passed
Test duration: 96 h
Wipe resistance of inscriptions
Specification: DINEN61010-1 (VDE0411-1):2011-07
DINEN62208 (VDE0660-511):2012-06 (in parts)
Testing in a condensation changing climate in the presence of sulfur dioxide
Specification: DIN50018:2013-05
Result: Test passed
Climate level: AHT 1.0 S
Cycles: 2
Salt spray test
Specification: DINEN60068-2-11:2000-02
Result: Test passed
Ambient conditions
Ambient temperature (operation): -40°C ... 150°C
Recommended storage conditions: 23°C/50% relative humidity. Storage in a dry and dark place in the original packaging is recommended.
Recommended ambient temperature (storage/transport): 23°C
Recommended humidity (storage/transport): 50 % (Storage in a dry and dark place in the original packaging is recommended)
Shelf life: 2years
Standards and regulationsWipe resistance: DINEN61010-1 (VDE0411-1)
MountingMounting type: adhesive
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_05526.pdf

Technical_drawing_04134.pdf
