M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 12, Direction of rotation: Standard, contact connection type: Socket, Solder-in connection, Axial O-ring, Central fastening M23 x 1, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242545

M23, Device connector, rear mounting, series: RC, straight, Screw locking mechanism, Radial O-ring, 4xM3, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242556

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 17, Direction of rotation: Standard, contact connection type: Pin, Solder-in connection, Radial O-ring, 4x Ø2,7, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242567

M23, Device connector, rear mounting, series: RC, straight, Screw locking mechanism, Flat gasket, 4x Ø 3.2, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 16+3, Direction of rotation: Standard, contact connection type: Pin, Solder-in connection, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, coding: N

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, contact connection type: Socket, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242587

M23, Device connector, rear mounting, series: RC, straight, Screw locking mechanism, Radial O-ring, 4xM3, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, contact connection type: Pin, Radial O-ring, 4x M2.5, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242595

M23, Device connector, rear mounting, series: RC, straight, Screw locking mechanism, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Pin, Crimp connection, Flat gasket, 4x Ø2,7, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, coding: X, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242681

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Socket, Solder-in connection, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242855

M23, Device connector front mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Pin, Solder cup, Axial O-ring, 4x Ø2,7, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242880

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 6+3, Direction of rotation: Standard, contact connection type: Pin, Solder pins, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1243196

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, No. of pos.: 6, Direction of rotation: Standard, contact connection type: Socket, Solder-in connection, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1243218

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, Axial O-ring, Central fastening M25 x 1.5, Panel thickness min.: 0.8 mm, Panel thickness max.: 6.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1243219

M23, Device connector rear mounting, series: RC, straight, Screw locking mechanism, No. of pos.: 12, Direction of rotation: Standard, contact connection type: Pin, Solder-in connection, Radial O-ring, 4x Ø 3.2, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption 6c (Pb < 0.1 %) item no.: 1244927

Panel mounting base, series: RC, straight, Screw locking mechanism, M23, Radial O-ring, 4xM3, shielded: yes, panel thickness min.: 3 mm, panel thickness max.: 10.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1240284

Panel mounting base, series: RC, straight, Screw locking mechanism, M23, Axial O-ring, Central fastening M25 x 1.5, shielded: yes, panel thickness min.: 0.8 mm, panel thickness max.: 6.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1240287

Panel mounting base
