Terminal Block, Screw Connection, Feed Through, 15.9 x 60 x 56mm (0.626 x 2.36 x 2.2 in), 1 Pole, Gray, Pkg. Qty. of 40, VOLTAGE RATING UR - 1000V AC/DC, CSA - 600V AC/DC, IEC - 1000V AC/DC, ATEX 690V AC/DC, MAXIMUM CURRENT RATING UR - 150A, C

1492-J IEC Terminal Block, One-Circuit Feed-Through Block, 35 mm (# 14 - # 1/0 AWG), Standard Feedthrough, Gray (Standard),

Product Code: 1492-J35

Partner cod.: 1492-J35

ROCKWELL AUTOMATION

Tecnichal data

Technical Specs

Download

Tecnichal data

BLOCK STYLEBase Block StyleStandard Feed-Through BlocksBASE DATABase Block TypeOne-Circuit Feed-Through BlockDETAIL DATAFeaturesStandard FeedthroughMaximum Wire Size & RatingUL: 12-2 AWG (115A @600V AC/DC) CSA: 12-2 AWG (115A @600V AC/DC) IEC: 35mm² (125A @1000V AC/DC) EEx e II: 35mm²/14-2 AWG (109A @ 750V AC/DC)ColorGray (Standard)

Technical Specs

Specifications
Special Features:Standard Feedthrough
Block Style
Base Block Style:Standard Feed-Through Blocks
Base Data
Base Block Type:One-Circuit Feed-Through Block
Detail Data
Features:Standard Feedthrough
Maximum Wire Size & Rating:UL: 12-2 AWG (115A @600V AC/DC) CSA: 12-2 AWG (115A @600V AC/DC) IEC: 35mm² (125A @1000V AC/DC) EEx e II: 35mm²/14-2 AWG (109A @ 750V AC/DC)
Color:Gray (Standard)

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

1492-td015_-en-p.pdf
